RS485 600mm Passage Ticket Reader Tripod Turnstile Gate

  • 1
  • 2

Brand Name : Goldantell

Model Number : GAT-DT301 series

Certification : CE certificate

Place of Origin : Guangdong,China

MOQ : 1pc

Price : negotiation

Payment Terms : T/T ,western Union,LC,Paypal

Supply Ability : 2,000pcs per month

Delivery Time : 7 working days after received your payment

Packaging Details : closed wooden case

Application : Company,hotel,airport

Power supply : 110~240 V(AC)

Direction : in or out, or two ways

Warranty : 1 year

Odm/oem : Accepted

Passage width : 600mm

Motor : DC Brushless motor

Contact Now

High quality fast detection ticket reader tripod turnstile Optimized 12 months warranty IC card security gate

Product Description

1.Tripod turnstile gate is compact and cost-effective entrance solutions.
2.The body is made of brushed stainless steel which is robust, rigid, anti-rust, and durable.
3.Tripod turnstile gate is ideal for indoor and outdoor settings.
4.It can be integrated with any kind of access controller system (e.g.: face recognition terminal, QR code scanner, RFID device, Push button, Fingerprint and Bio-metric device).
6.In case of emergency, the tripod turnstile gate will drop down automatically when power off.

Technology Parameters
Size 1400mm (L) * 280mm (W) * 1000mm (H)
Working voltage AC110/220±10%V, 50±10%HZ
Working movement DC24V solenoid valve
Arm width: 510 mm
Support force of arm: 60kg
Passage width: ≤600 mm
Time of opening: 0.2 second
Pass speed: 30 persons/min
Emergence: When power off, arms open automatically
Normal running life: 3 million
LED light: direction arrow
Direction: single or bi-directional (optional)
Working environment: indoor/outdoor (with a tent over) -10℃~70℃
Relative humidity: ≤90% coagulation free
Communication interface: standard RS485 interface, distance ≤1200m
Housing material domestic standard 304# stainless steel
Input interface:

+12V level signal or pulse width>100ms 12V pulse, drive current>10mA

Feature & Function

1. Auto replacement function, re-position after person pass by.
2 Anti -tail function auto-lock once turn120° or 60°.
3. Arms auto drop when power off, ensure unblocked when accident.
4. Standard electronic interface, remote control through internet which is also could connect variety card readers and receive relay signal to work.
5. Diverse control mode optional, changeable due to varying, convenient for your manage.

Application Location

♦ Public Places: lobby entry, Subway, Airports, Stations,Library, Bookstores, Parks, Exhibition halls, Stadium, Museums,Apartments,Residence Area, Offices,Commercial buildings.

♦ Entertainment Places: Movie theaters, Fitness halls, Country clubs, Fairground, Clubs,Swimming Hall, Fitness Gym.

♦ Business Organizations: Hotel,Factory,Bank,Prison,Hospital,School, Enterprise’s Entrance and Exit Attendance.

Details Photos
RS485 600mm Passage Ticket Reader Tripod Turnstile Gate
Factory Photos
RS485 600mm Passage Ticket Reader Tripod Turnstile Gate
FAQ

Q. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q. What is your sample policy?
A: We offer samples if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

Q. Do you test all your goods before delivery?
A: Yes, we have the 100% test before delivery, and will provide a testing video for your confirmation before shipment.
