Bus station three arm gate tripod turnstile for Intelligent flow control

Name: Bus station three arm gate tripod turnstile for Intelligent flow control
Brand: Goldantell
Price: 1 USD

Brand Name : Goldantell

Model Number : GAT-622

Certification : CE/ROHS/FCC/IS9001

Place of Origin : Guangdong,China

MOQ : 1pc

Price : negotiation

Payment Terms : T/T ,western Union,LC,Paypal, L/C

Supply Ability : 2,000pcs per month

Delivery Time : 7 working days after received your payment

Packaging Details : Packed in carton firstly,and then reinforced with export wooden case for outer packing

Motor : DC24V solenoid valve

Housing material : domestic standard 304# stainless steel

Time of opening/closing : 0.6second

Passage width : 600mm

Application : indoor and outdoor

Support force of arm : 60kg

Emergence : When power off, arm open automatically

Input interface : +12V level signal or pulse width>100ms 12V pulse, drive current>10mA

LED light : direction arrow

Direction : single or bi-directional (optional)

Contact Now

Bus station three arm gate tripod turnstile for Intelligent flow control

Specifications:

Item	GAT-307
Working voltage:	AC220±10%V 50±10%HZ
Time of opening	0.6second
Passage width	600mm
Reset time after break down	10 seconds
Integration	machine, electronics, micro-processor control and ID identification
Direction:	single or bi-directional (optional)
Transit speed	30-40 people/minute
Input interface:	RFID Reader&Fingerprint Reader ,Coin acess,QR code reader, Bar code System,ESD Tester Access Control, remote button
Communication interface	RS485/232
Emergence:	When power off, arm open automatically

Features:

The Tripod Turnstiles are very robust products able to function inside and outside buildings.
The Tripod Turnstile is a waist-height tripod turnstile in a self-supporting housing (2 Feet).
The Tripod Turnstile with dropping arm to free the walkway in the event of an emergency or for certain applications
. Active arm can drop clear (emergency or application)
. Arms cannot be removed without special tools
. Mechanism cannot be forced
. Inactive arms do not hinder the passage
. Simple to install
. Removable end covers for easy integration of any type of access control device
. Numerous configurations covering all cases of pedestrian access control

Appearance, Material & Surface Finish:

stainless steel thickness of the cabinet: customized within 1.2~2.0mm.
Material of the cabinet: 304 / 316 grade stainless steel.
Surface finish of the cabinet: satin finish / polishing / anti-fingerprint/frosted finish / electroplating / baking finish.

Control system:

RFID Reader&Fingerprint Reader
Coin acess,QR code reader
Bar code System
ESD Tester Access Control
Remote button

Application:

Supermarket
Subway Station, Bus Station
,Airports
Tourism
Exhibition
Theater
Swimming Hall
Fitness Gym
Residence Area
Enterprise’s Entrance and Exit Attendance
Toll Management

Direction Indicator:

The installation position of direction indicator can be adjusted.
The pattern of direction indicator can be customized

System integration:

Integrate with access control system required by customers, and built-in reader appointed by customer.
Integrate with visitor management system.
