Supermarket coin operated RFID Turnstile with alarm function and reset function

Name: Supermarket coin operated RFID Turnstile with alarm function and reset function
Brand: Goldantell
Price: 1 USD

Brand Name : Goldantell

Model Number : GAT-612

Certification : CE/ROHS/FCC/IS9001

Place of Origin : Guangdong,China

MOQ : 1pc

Price : negotiation

Payment Terms : T/T ,western Union,LC,Paypal, L/C

Supply Ability : 2,000pcs per month

Delivery Time : 7 working days after received your payment

Packaging Details : Packed in carton firstly,and then reinforced with export wooden case for outer packing

Product Name : Supermarket RFID swing barrier gate with alarm function and reset function

Motor : DC24V solenoid valve

Housing material : domestic standard 304# stainless steel

Working environment : Working environment: indoor/outdoor (with a tent over) -10℃～70℃

Compatible : RFID Reader&Fingerprint Reader ,Coin acess,QR code reader,Bar code System,ESD Tester Access Control, remote button

Swing arm angle : 180 degree

Time of opening/closing : 1 second

Passage width : 530-830mm

Pass speed : Pass speed: 40 persons/min (open), 25-30 persons/min (closed)

Working voltage : AC220±10%V 50±10%HZ

Reset time after break down : 10s

Contact Now

Supermarket RFID coin operated turnstiles with alarm function and reset function

Specifications:
Item	GAT-612-1( single motor )
Working voltage:	AC220±10%V 50±10%HZ
Passage width	530-830mm
Pass speed:	40 persons/min (open), 25-30 persons/min (closed)
Reset time after break down:	10 seconds
Direction:	single or bi-directional (optional)
Input interface:	RFID Reader&Fingerprint Reader ,Coin acess,QR code reader, Bar code System,ESD Tester Access Control, remote button
Communication interface	RS485/232
Swing arm angle	180 degree
Time to work after power on	3 seconds
OME	OEM arm length,custom logo,custom size

Function:

1. The gate is Bidirectional, according the infrared sensing to enter and exit the passageways.

2. Turnstile can setting the working condition by press the button of main control board.

3. Anti-pinch function: turnstile have Mechanical/ infrared induction Anti-pinch functions( when it is meet the hinder during the reset time, the electrical machine closed work automatically in specified time, the turnstile will default the delayed and reset again till reset succeed)

4. The turnstile will lock when somebody enter the gate illegal, Tailgating or break into negative direction gate.

5. Before received the open signal, the turnstile will lock automatically

6. The arm have the collision avoidance function: when the turnstile arm closed, if it is under the collision, the arm will open to protect the Transmission of inner machine.

7. Automatic Reset Functions: after you swap the card, during the specific time (the system is 10s), if you didn’t pass the turnstile, the system will cancel your authority automatically to pass the gate, (reset time is 1~60s you can adjust it what time is suit for you). totally meet the fire protection needs

8. Can manager and long-range control the turnstile directly by managing the computer.

9. The turnstile is bidirectional (pedestrian can enter and exit from one pair of turnstiles)

10. Can manager and long-range control the turnstile directly by managing the computer.

Extended Function:

1.LED counting function

2.Box house can lengthen, swing arm lengthen

3.Infrared logical judgment function (you can choose 8 pairs or 10 pairs Infrared)

4. Normally open or closed can be adjust to meet the requirements of the different place.

5.Voice Prompt Function /Sound and light alarm prompt functions

Competitive Advantage:

1.More than 10 years powerful ODM/OEM ability,could make product shape design,custom logo,custom package.

2. we can provide not only product, but also system software management.Save your time and cost.

3.Special service from Goldantell:

For repairing,no need you return back product,only need you take a video,our engineer will instruct you,if spare parts was damaged in 1 year,we will send you spare parts by fastest express,you no need bear any fee.
